RA942-I / RA942-IF HARVESTER

Automatic two-row (rear-mounted receptacle) machine.

Description

Model conceived and manu-factured for the automated harvesting of tobacco leaves.

The RA942I harvester, which operates on inter-row from 110 to 140 cm , the RA942IF harvester, which operates on inter-row from 90 cm, width has 4-wheel drive powered by a hydrostatic drive system with wheels that steer only with the front axle.

Machine type-approved for circulating on the road.

The tobacco leaves are picked gradually starting from the lowest and working upwards, according to maturity, working two rows simultaneously.

The leaves are pulled off the plant as they are struck by spinning rubber spirals on two bars (defoliating unit).

A grate-type or knives-type defoliator, mounted instead of the two bars, removes the top leaves.

The defoliation is due to special defoliators, placed to pendulum, which follow the straightness of the rows.

The detached leaves are sent by metal rollers onto vertical conveyor belts that, in turn, lift them toward the storage receptacle, into which they are blown by a continuous flow of air.

The container, placed in the rear of the machine, for the discharge phase in trolleys, raises and opens on operator command.

Technical features RA942-I

Inter-row (to be specified at order confirmation) from 110 to 140 cm
Harvesting roms 2
Defoliators alignment feeler with electro hydraulic sensors
Defoliators standard: rubber for lower and medium leaves
Engine: FPT (TIER 3A)*
– cycle / stokes / cylinders diesel / 4 / 4 in line
– total displacement 4.485 cm³
– maximum power 74 Kw to 2.300 rpm
– maximum torque 435 Nm to 1.250 rpm
Total empty ewight: 6.300 kg
Steering: hydraulic
Brakes: hydrostatic
Wheels: 4 drive wheels with 20” rims
2 front steering wheel
Tires (1st and 2nd axle): 14,5 R20
Drive: Reversible Hydrostatic Drive
With Forward/Reverse Lever
Maximum road speed: 25 Km/h
Battery: N°1 – 12 V 145 Ah
Fuel tank: Capacity 210 lt
Code 100 050 942

(*) Other engine on request

Technical features RA942-IF

Inter-row (to be specified at order confirmation) from 90 cm
Harvesting roms 2
Defoliators alignment feeler with electro hydraulic sensors
Defoliators standard: rubber for lower and medium leaves
Engine: FPT (TIER 3A)*
– cycle / stokes / cylinders diesel / 4 / 4 in line
– total displacement 4.485 cm³
– maximum power 74 Kw to 2.300 rpm
– maximum torque 435 Nm to 1.250 rpm
Total empty ewight: 6.000 kg
Steering: hydraulic
Brakes: hydrostatic
Wheels: 4 drive wheels with 20” rims
2 front steering wheel
Tires (1st and 2nd axle): 14,5 R20
Drive: Reversible Hydrostatic Drive
With Forward/Reverse Lever
Maximum road speed: 25 Km/h
Battery: N°1 – 12 V 145 Ah
Fuel tank: Capacity 210 lt
Code 100 052 942

(*) Other engine on request

Accessories

  • Complete grate-type defoliator (pair)

  • Complete blade-type defoliator (pair)

  • Complete stalk cutter (pair)

  • Air conditioning unit

RA341 HARVESTER

Automatic one-row (rear-mounted receptacle) machine.
Model conceived, manufactured, and patented for the automated harvesting of tobacco leaves.

The RA341 harvester, which operates from 115 cm inter-row width has 4-wheel drive powered by a hydrostatic drive system with wheels that steer only with the front axle.

Machine type-approved for circulating on the road.

The tobacco leaves are picked gradually starting from the lowest and working up-wards, according to maturity, working one row at a time.

The leaves are pulled off the plant as they are struck by spinning rubber spirals on two bars (defoliating unit).

A grate-type defoliator, mounted instead of the two bars, removes the top leaves.

The precision and reliability of the defoliation are guaranteed by special electro-hydraulic sensors that constantly feel and follow the contour of the terrain and the straightness of the rows.

The detached leaves are sent by metal rollers onto vertical conveyor belts that, in turn, lift them toward the storage receptacle, into which they are blown by a continuous flow of air.

The receptacle, situated on the rear part of the machine, may be emptied when full by dumping into trucks for transport.

Technical features

Minimum Inter-row  (to be specified at order confirmation) 115 cm
Harvesting rows 1
Defoliators alignment feeler with electro hydraulic sensors
Defoliators standard: rubber for lower and medium leaves
Engine: VM D754 TE3 (TIER 3A)*
– cycle / stokes/ cylinders diesel / 4 / 4 in linea
– total displacement 2.970 cm³
– maximum power 59,8 Kw a 2600 rpm
– maximum torque 274 Nm a 1800 rpm
Total empty ewight: 4400 kg
Steering: hydraulic
Brakes: hydrostatic
Wheels: 4 drive wheels with 18” rims – 2 front steering wheel 10,5 R18
Tires (1 st and 2nd axle): 10,5 R18
Drive : reversible hydrostatic drive with forward/reverse lever
Maximum road speed: 20 km/h
Battery: N°1 – 12 V 145 Ah
Fuel tanck: Capacity 110 lt
Code 100 050 341

(*) Other engine on request

Accessories

  • Grate-type defoliator

  • Stalk cutter

  • Spraying and treatment unit kit with tanck (300 + 300 L)

  • Air conditioning unit Kit

STN BULK CURING BARN, SINGLE

The traditional barn single module for tobacco

The traditional barn SINGLE MODULE  mod. STN for tobacco bulk curing stands for green tobacco filler in special baskets. The hot air produced by a generator through the tobacco from below upwards it makes drying. A controller with a preset and adjustable program monitors and manages the entire oven cycle, guaranteeing a perfect cure.

Loading: carried out by introducing Green tobacco containers inside the barn on two raised platforms that allow a perfect aeration inside containers during the drying phase.

Unloading: once the drying cycle, the containers are taken from the barn and subsequently flushed from tobacco leaves.

ETN BULK CURING BARN, MODULAR

The traditional barn modular drying and curing solutions for tobacco

The traditional barn mod. ETN (MODULAR SYSTEM) for tobacco bulk curing stands for green tobacco filler in special baskets. The hot air produced by a generator through the tobacco from below upwards it makes drying. A controller with a preset and adjustable program monitors and manages the entire oven cycle, guaranteeing a perfect cure.

Loading: carried out by introducing Green tobacco containers inside the barn on two raised platforms that allow a perfect aeration inside containers during the drying phase.

Unloading: once the drying cycle, the containers are taken from the barn and subsequently flushed from tobacco leaves.

Spapperi Transplanters

BARE-ROOTED, CONICAL, CYLINDRICAL, PYRAMID AND CUBIC PLANTS:

TU SERIES

Rapier transplanter model TU:
Minimum inter-row standard 45 cm – double frame 25 cm

Models:

PLANTS WITH CONICAL, CYLINDRICAL AND PYRAMID PLATE:

TC SERIES

Transplanter distributor 12 holes model TC
Minimum inter-row standard 45 cm

Models:

TRANSPLANTING PLANTS WITH CONICAL, CYLINDRICAL, PYRAMID, CUBIC, SEEDS AND BULBS PLATE:

AS SERIES

Perforating cup transplanter
